HIKMICRO M20W Handheld Thermal Camera

HIKMICRO M20W handheld thermography camera is specially designed for professional inspections of large objects where a wider FOV captures more of the scene in one picture. It’s equipped with a 256 × 192 resolution thermal detector, 50° x 37.2° fixed focus lens, and an 8MP resolution visual camera. The high resolution 3.5-inch touch screen displays crisp, clear images and streamlines camera operations. Imaging modes include thermal, visual, picture in a picture of the optical and thermal view, and fusion of both channels. The M20W quickly identifies potential faults and quantifies the impact with accurate temperature measurement, provides detailed documentation to complete your inspections efficiently.

Key Features

• High sensitivity thermal module with 256 × 192 resolution
• Supports multiple palettes
• High quality optical module with 8 MP resolution
• Bi-spectrum image fusion, picture-in-picture preview
•  Wide temperature measurement range: -20 – 650° C
• High temperature measurement accuracy: Max ±2°C for 0 to 100°C, ±2% for 100 to
• 600°C, ±4% for 600 to 650°C at the ambient temp. 15 to 35°C
•  640 x 480 resolution 3.5” LCD touch display
•  Long-distance laser light supplement for thermography targets
• LED light supplement makes the device a torch in required scenarios
• 1.0x to 8.0x continuous digital zoom
• Supports remote album access, download and quick report with APP.
