2022 Stefani MDR Automatic Edgebander – Florida

Technical Specifications Glue Pot Unit:

Heating Time

Approx. 8-10 min.

Pot/Hopper Capacity

1.1 lbs. / 8.8 lbs.

Pre-milling Station:

Horsepower

5.25 HP ea.

RPM

12,000 RPM

Max. Stock Removal

90mm²

Diameter/Bore/Height

100mm/30mm/49mm

End Cutting Trimming Station:

Horsepower

.75 HP ea.

RPM

12,000 RPM

Tilting

0-15 degrees

Blade Diameter/Bore

100mm/32mm

Flush Edge Trimming Unit:

Horsepower

1.5 HP ea.

RPM

12,000 RPM

Cutting Tools

70x20x16mm

Tiltable Edge Trimming Unit:

Horsepower

1.5 HP ea.

RPM

12,000 RPM

Tilting

0-25 degrees

Cutting Tools

70x20x16mm

3mm radius knives

Corner Rounding Unit::

Horsepower

.80 HP ea.

RPM

12,000 RPM

Cutting Tools

3mm / 1mm

Scraping Unit:

Knife Radius

1mm and 3mm inserts

Buffing Unit::

Horsepower

.25 HP

RPM

3,000 RPM

Diameter/Bore

152mm/17mm

Feed Motor Horsepower

2.5 HP

Feed Speed

40-72 FPM

Frequency Converter

200 Hz

Pneumatic Operating Pressure

90 PSI

Machine Weight:

9,105lbs.

Electrical:

130 amps @ 230v three phase

Dust:

3,500 cfm

Dimensions (LxWxH):

262” x 65” x 62”
