GAS MAD PM2-64

GAS MAD2 is a more robust and stronger-sounding collection of MAD speakers, which offers a better price-quality ratio than ever before!

As a novelty, the MAD PM2 collection covers not only 6.5″ and 8″ elements but also 10″ SPL elements for the first time!

---

Stronger than ever
The MAD PM2-64 is not made for playing any quiet background music, but the MAD “second” is made to play louder than ever.

The element has a high sensitivity of 94dB, a reinforced really durable paper pulp cone, a stylish 3D patterned polypropylene dust cup and a sturdy metal frame. The voice coil and magnet are larger than the PM1 models.

However, the most significant innovation is that the resonance frequency has been lowered to 90 hertz. So a lot of sound is promised for little money.

---

How much do we put?
Even if it’s a lot, because at this price, two, four or eight pairs won’t break the bank, but you’ll still get a sound for it.

---

How to connect the elements:

1 pair, 4ohm / channel

—–

2 pairs, 2 ohm / channel

—–

2 pairs, 8 ohm / channel

—–

4 pairs, 1 ohm / channel

—–

4 pairs, 4 ohms / channel

Important: Before connecting, make sure that your amplifier can handle that load!

---

Technical information:

• 6.5″ SPL midrange
• Impedance: 4ohm
• 1.5″ voice coil
• Metal frame
• A cone of reinforced paper pulp
• Sensitivity: 94dB
• Playback range: 90 – 12,000Hz
• Power duration (RMS / Max): 100W / 200W
• Outer diameter: 165mm
• Sink hole: 144mm
• Immersion depth: 74mm
• In the package: 1 pair

Electrical values:

• VAS: 7.52 L
• Qts: 0.76
• Qes: 0.84
• Qms: 7.08
• Re: 3.4 Ohm
• Fs: 98.7 Hz

---

Note: These are also available as ready-made, inexpensive separate sets with MAD splitters, MAD SPL trebles and, depending on your choice, one or two pairs of MAD SPL midranges.
