JET 708677PK 5-Hp 230V 50″ Heavy Duty Cast Iron RIP Deluxe Xacta Saw
$190.99
Features
EXCLUSIVE 30″ Commercial XACTA® Fence II with T-square design
Quick release riving knife greatly reduces binding/kickback risk
Push button arbor lock for rapid blade change
Shrouded Blade increases dust collection efficiency
Standard 11″ left…
Features
- EXCLUSIVE 30″ Commercial XACTA® Fence II with T-square design
- Quick release riving knife greatly reduces binding/kickback risk
- Push button arbor lock for rapid blade change
- Shrouded Blade increases dust collection efficiency
- Standard 11″ left and right cast iron extension wings provides the largest table surface in its class
- Poly-V drive belt system delivers quiet, efficient operation
- Rail-mounted magnetic switch is easy to reach and provides overload protection
- Deluxe miter gauge with adjustable positive stops and large soft grip handles provides large crosscutting capacity and accurate miters
- Heavy-duty chrome plated handwheels contribute to smooth trunnion/arbor movement
- Built-in 4″ dust collection port
- Precision ground high luster cast iron table tops with front edge bevel for hassle-free workpiece positioning
- Left tilt, Wide stance heavy-duty trunnion for stability and smooth blade positioning
- Independent leaf safety guard protects operator from blade while cutting, even at 45° tilt
- Arbor wrench
- Powder coated paint for a long-lasting, chip-resistant finish
What’s in The Box
- Deluxe Xacta Saw 5HP, 1Ph, 50″ RIP 708677PK
- Owner’s Manual
Warranty
- JET Red Assurance 2-Year Warranty
- 30 Day Satisfaction Guaranteed
Specifications
| Blade Diameter (In.) | 10 |
| Arbor Diameter (In.) | 5/8 |
| Arbor Speed (RPM) | 4300 |
| Maximum Depth of Cut (In.) | 3 |
| Maximum Depth of Cut at 45 Degrees (In.) | 2-1/8 |
| Maximum Rip Left of Blade (In.) | 13 |
| Maximum Rip Right of Blade (In.) | 50 |
| Table in Front of Saw Blade at Maximum Depth of Cut (In.) | 10 |
| Maximum Diameter of Dado (In.) | 8 |
| Maximum Width of Dado (In.) | 13/16 |
| Table Type | Cast Iron |
| Table Size (L x W) (In.) | 29 x 20 |
| Table Size with Extension (L x W) (In.) | 29 x 42 |
| Miter Gauge Type | Deluxe |
| Dust Collection Minimum CFM Required (CFM) | 350 |
| Dust Port Outside Diameter (In.) | 4 |
| Motor Power (HP) | 5 |
| Motor Phase (PH) | 1 |
| Motor Voltage (V.) | 230 |
| Prewired Voltage (V.) | 230 |
| Motor Amps | 18 |
