Application
| System | Free from silicone; gold-plated contacts; screened cable; Drag chain suitability |
|---|---|
| Application | sanitary and wet areas in the food industry |
| Free from silicone | yes |
Electrical data
| Operating voltage [V] | < 50 AC / < 60 DC |
|---|---|
| Protection class | III |
| Max. current load total [A] | 4 |
| Overall current rating (UL) [A] | 3 |
Operating conditions
| Ambient temperature [°C] | -25…100 | |
|---|---|---|
| Note on ambient temperature |
|
|
| Ambient temperature (moving) [°C] | 5…100 | |
| Note on ambient temperature (moving) |
|
|
| Protection | IP 65; IP 67; IP 68; IP 69K |
Mechanical data
| Weight [g] | 488.5 | ||||||||
|---|---|---|---|---|---|---|---|---|---|
| Dimensions [mm] | 15.5 x 15.5 x 45 | ||||||||
| Material | housing: PVC orange; sealing: EPDM | ||||||||
| Material nut | stainless steel (1.4404 / 316L) | ||||||||
| Drag chain suitability | yes | ||||||||
| Drag chain suitability |
|
Remarks
| Pack quantity | 1 pcs. |
|---|
Electrical connection
| Cable: 10 m, PVC, orange, Ø 5.2 mm, screened; 4 x 0.34 mm² (42 x Ø 0.1 mm ) |
Electrical connection – Socket
| Connection | Connector: 1 x M12, straight; coding: A; Locking: stainless steel (1.4404 / 316L); Contacts: gold-plated; Tightening torque: 0.6…1.5 Nm; Shielded connection cable: shield connected |
|---|
Diagrams and graphs
| Shielding characteristics
|
|
|---|
