Mobile Precision 7680/I7-13850Hx/32/1Tb/16/Rtx2000

MOBILE PRECISION 7680/I7-13850HX/32/1TB/16/RTX2000

DELL Precision 7680. Product type: Mobile workstation, Form factor: Clamshell. Processor family: Intel® Core™ i7, Processor model: i7-13850HX. Display diagonal: 40.6 cm (16″), HD type: Full HD+, Display resolution: 1920 x 1200 pixels. Installed RAM: 32 GB, Internal memory type: DDR5-SDRAM. Total storage capacity: 1 TB, Storage media: SSD. On-board graphics adapter model: Intel® UHD Graphics, Discrete graphics adapter model: NVIDIA RTX 2000. Operating system installed: Windows 11 Pro. Product colour: Grey

True Accelerometer

---

Bluetooth true

---

Realtek ALC3281 audio chip

---

Product color Grey

---

Clamshell form factor

---

True integrated card reader

---

Trusted Platform Module (TPM) true

---

True Hall Effect Sensor

---

True ambient light sensor

---

Memory slot Not available

---

SSD storage support

---

Optical drive type N

---

Video capture speed (fps) 30

---

Power adapter output AC (A) 9.23

---

AC frequency adapter 50 – 60 Hz

---

AC input voltage adapter 100 – 240 V

---

AC 19.5V output voltage adapter

---

AC adapter power dissipation (W) 180

---

Lithium-Ion (Li-Ion) battery technology

---

Charging port type DC-in jack

---

Battery voltage (V) 11.55

---

Separate graphics card adapter true

---

Dedicated graphics card model NVIDIA RTX 2000

---

Integrated graphics card model Intel UHD Graphics

---

Integrated GPU Manufacturer Intel

---

NVIDIA GPU Discrete Manufacturer

---

Maximum resolution of discrete graphics card 7680 x 4320 pixels

---

Maximum resolution of integrated graphics card 7680 x 4320 pixels

---

True integrated graphics card

---

Graphics card memory type GDDR6

---

Height (front) (mm) 22.3

---

Height (mm) 23.2

---

Height (rear) (mm) 23.2

---

Width (mm) 356

---

Weight (g) 2600

---

Depth (mm) 258.34

---

Operating altitude -15.2 – 3048 m

---

Non-operating altitude -15.2 – 10668 m

---

Temperature range -40 – 65 °C

---

Operating temperature range 0 – 35 °C

---

Operating humidity range 10 – 90%

---

Operating shock (G) 110

---

Non-operation shock (G) 160

---

Humidity 0 – 95%

---

Operating vibration (G) 0.66

---

Non-operating vibration (G) 1.3

---

Intel® vPro™ Platform Eligibility true

---

Intel® Flex Memory Access true

---

Intel® Virtualization Technology for Directed I/O (VT-d) true

---

Intel® VT-x with Extended Page Tables (EPT) true

---

Intel® Virtualization Technology (VT-x) true

---

Year of introduction 2023

---

SSD Capacity (GB) 1000

---

CPU configuration (max) 1

---

M.2 SSD Size

---

Memory form factor CAMM module

---

True NVMe

---

Built-in options available false

---

Installed RAM (GB) 32

---

Product type Mobile workstation

---

RAM Type DDR5-SDRAM

---

Memory Speed ​​(MHz) 5600

---

64-bit operating system architecture

---

Trial Software No Microsoft Office License Included 30 day Trial Offer Only

---

True cable lock

---

Slot type cable lock Wedge

---

Processor cache (MB) 30

---

Intel Core i7 Processor Family

---

Processor Frequency Max Turbo Efficient-core (GHz) 3.8

---

Processor Turbo Frequency Maximum Performance-core (GHz) 5.3

---

Intel Core i7-13xxx Processor Generation

---

Processor model i7-13850HX

---

Number of processors supported 1

---

Intel Processor Manufacturer

---

Configurable TDP-down (W) 45

---

DMI4 bus type

---

Processor cache type Smart Cache

---

Dual-channel memory channels

---

Dedicated Graphics Memory (GB) 8

---

Non-ECC true

---

Maximum RAM supported (GB) 128

---

Memory structure 1 x 32

---

Battery capacity (Wh) 83

---

Number of battery cells 6

---

Battery weight (g) 383

---

Fast charging true

---

Charging time (h) 3

---

Total SSD capacity (GB) 1000

---

Solid State Drive (SSD) PCI Express 4.0 interface

---

Number of SSDs installed 1

---

Total storage capacity (GB) 1000

---

AC cables included

---

True LAN Ethernet Connection

---

Fake mobile network connection

---

Intel Wi-Fi 6E AX211 WLAN Controller Device Model

---

Intel WLAN Controller Manufacturer

---

Wireless LAN data transfer rate (max) 2400

---

WWAN Upgradeable

---

7.4mm Power Adapter Cylindrical Connector

---

Intel® Thunderbolt 4 True

---

True combo microphone/headphone jack

---

Thunderbolt 4 ports quantity 2

---

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2

---

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity 1

---

Ethernet LAN ports quantity (RJ-45) 1

---

HDMI ports quantity 1

---

Pixel Density (ppi (dots per inch)) 142

---

Screen size (“) 16

---

Color range (%) 100

---

Screen brightness (cd/m²) 500

---

Native aspect ratio 16:10

---

Contrast ratio 1300:1

---

True LED backlight

---

RGB color space DCI-P3

---

Display resolution 1920 x 1200 pixels

---

True anti-glare screen

---

Maximum refresh time (Hz) 60

---

WLED panel type

---

Touch screen fake

---

Touchpad pointing device

---

Fake fingerprint reader

---

Number of keyboard buttons 100

---

True Numeric Keypad

---

true backlit keyboard

---

True front camera

---

Front camera resolution 1920 x 1080 pixels

---

Front camera resolution (numeric) (MP) 0.92

---

Front camera HD type Full HD

---

True Infrared (IR) Camera

---

True smart card reader

---

Password protection true

---

Trusted Platform Module (TPM) version 2.0

---

True Built-in Microphone

---

Mouse included only on selected markets false

---

Number of microphones 2

---

Number of built-in speakers 2

---

Speaker power (W) 2

---

3Y ProSpt Warranty Period and Type

---

Business Market Positioning

---

Operating system included Windows 11 Pro

---

Antenna type 2×2

---

HD Type Full HD+

---

Standard Wi-Fi Wi-Fi 6E (802.11ax)
