COMPCOOLER Motorcycle Rider Chiller Cooling Unit 200W DC 12-16V vehicle power operated
$16.99
Motorcycle Rider Liquid Chiller SystemModel: COMP-MLC-12200VOperation Manual for HandCarry Chiller UnitCompcooler Motorcycle Rider Liquid Chiller System (MLCS) was designed for the body cooling of riders. MLCS uses 12V DC rotary compressor refrigeration system to cool the liquid, pump circulates the cold liquid to cooling vest, then flow back to reservoir…
Motorcycle Rider Liquid Chiller System
Model: COMP-MLC-12200V
Operation Manual for HandCarry Chiller Unit
Compcooler Motorcycle Rider Liquid Chiller System (MLCS) was designed for the body cooling of riders. MLCS uses 12V DC rotary compressor refrigeration system to cool the liquid, pump circulates the cold liquid to cooling vest, then flow back to reservoir after heat exchanged. MLCS delivers 400W cooling capacity, power by DC12V vehicle power or rechargeable battery. temp control -5℃ to 30℃ (23℉ to 86℉), accuracy +/-1℃ (2℉), once circulation liquid reaches to set point temperature, system intellectually control the cooling capacity to that temperature. User may pre-cool the unit and get the coldest liquid as he needs, iceless cooling unit, maintain free.
Components List:
|
Item |
Part number |
Description |
Quantity |
|
1 |
COMP-HLCU |
Handcarry Liquid Chiller Cooling Unit |
1 |
|
DC Connection Power Cord EC5 |
1 |
||
|
2 |
COMP-ET1M |
Extension Tubing 1 meters |
1 |
|
|
Operation Manual |
1 |
Chiller Unit Technical Datasheet
|
Cooling Capacity (Ambient Temp. 40℃) |
W |
200 |
|
|
Cooling Capacity (Ambient Temp. 104℉) |
Btu |
682 |
|
|
Max Cooling Capacity |
W |
300 |
|
|
Power Supply |
Rated Voltage V |
12 |
|
|
Operation Voltage Range |
12-16V |
||
|
Operation Current |
A |
12 |
|
|
Max Current |
A |
15 |
|
|
Max Power Consumption |
W |
200 |
|
|
Refrigerant |
Type |
|
R134a |
|
Temp Control |
℃ |
-5 to 30 |
|
|
℉ |
23-86 |
||
|
Coolant |
Anti-freeze liquid |
|
Yes |
|
Rotary Compressor (Samsung) |
Qty |
PC |
1 |
|
Voltage |
V DC |
12 |
|
|
Discharge |
CC |
1.9 |
|
|
Speed |
RPM |
2000-6500 |
|
|
Fan |
Qty |
PC |
2 |
|
Voltage |
V DC |
12 |
|
|
Air Flow |
CFM |
30 |
|
|
Pump |
Voltage |
V DC |
12 |
|
Water flow |
L/Min |
1 |
|
|
Lift |
M |
2 |
|
|
Power Connector |
Type |
DC |
EC5 |
|
Operation Ambient |
Max |
℃ |
-10 to 60 |
|
Storage Temp |
|
℃ |
-20 to 70 |
|
Noise |
Max |
dBA |
58 |
|
Color |
|
White or Black |
|
|
Dimension |
L x W x H |
mm |
220x180x100 |
|
Inch |
8.6×7.1×3.9 |
||
|
Weight |
KGS |
4 |
|
|
LBS |
8.8 |
