Evapco PMC-560 Evaporative Condenser (560 Nominal Tons,1-20 HP Motor)

Number Units in Package: 1
Nominal Tons (total): 560 TR*
Ammonia Tons (total): 406 TR*

R-717 (ammonia) or R22 (freon). Last run with Ammonia.
Design pressure:  PSIG
Pump Requirements (per unit):
Pump Included? No, can purchase separately
Fan Details (per unit): 3 fans. Baldor Electric motor: 7.5 hp, 1765 rpm, 460 V, 9.40 A, 60Hz, 3 phase. Baldor Electric motor: 20 hp, 1760 rpm, 230/460 V, 48/24 A, 60 Hz, 3 phase.

Top Dimensions (per unit): 19’3 L x 10′ W x 5’10 H
Top Weight (per unit): 22,282 LBS
Bottom Dimensions (per unit): 19’3 L x 10′ W x 9’8 H
Bottom Weight (per unit): 7,427 LBS

Notes: Fans missing. Coil has been successfully leak tested.

*Tons at standard conditions: 96.3°F condensing, 20°F suction and 78°F Wet Bulb

Can sell one tower unit from a group upon request for a fee. Please request as needed.
