Dave Vertical Windlass – Right Chain Pipe

The Dave is a vertical application windlass perfect for boats with limited deck space. This unit is composed of AISI 316 stainless steel which is a durable element when dealing with harsh marine environments.

This unit comes in different variations such as with or without the drum capstan for rope retrieval, left and right side chain entry as well as various gypsy sizes for rope and chain retrieval. Equipped with an emergency manual lift system you can easily retrieve your anchor during instances when you may lose battery power on your boat. Additional features include an IP67 watertight motor, anodized aluminium gearbox, and an easy to open inspection lid.

This unit is sold complete with the windlass, solenoid unit, clutch handle and mounting hardware.

	10 mm – 3/8″	12/13 mm	14 mm
	10 mm	10 mm	3/8″	3/8″	13 mm	12 mm	7/16″	14 mm	1/2″
DIN 766	ISO	G4	BBB	DIN 766	ISO	G4	DIN 766	G4
	3/4″	3/4″	3/4″
