CS8264C | Leviton Industrial Grade Connector

Description

The Leviton CS8264C is an industrial-grade, California-Style locking connector designed for demanding applications.





Technical Specifications

Condition	New/Never Used Surplus
Brand	Leviton
Category	Connectors
Part Number	CS8264C
Subcategory	Electrical Plugs & Receptacles
Amperage Rating	50, 50 A
Cord Diameter	3/4 to 1-1/8, 3/4 to 1-1/8 in
Dimensions	6.34 in L x 2.59 in W, 6.5 x 2.56 x 2.5, 6.5 x 2.56 x 2.5 in
Enclosure	IP20
Number of Poles	2
Number of Wires	3
Series	CS Series
Temperature Rating	-40 to 75°C
Terminal Type	Pressure Screw
Voltage Rating	250, 250 VAC
Color	Black/White
Material	Composite, Nylon
Weight	0.45 kgs





Information About CS8264C

The CS8264C is a heavy-duty, industrial-grade locking connector designed for demanding electrical applications. Manufactured by companies like Leviton and Hubbell, this connector is built to withstand harsh environments and provide reliable performance.

Key Features:

• Electrical Rating: 50 Amps, 250 Volts AC, 2-pole, 3-wire grounding configuration.

• Design: Non-NEMA, California-Style (CS) locking connector with a black and white color scheme.

• Construction: Durable nylon housing resists impact, sunlight, chemicals, and rough use. The thermoplastic polyester interior provides heat resistance and impact strength.

• Cord Compatibility: Accepts cord diameters ranging from 0.830 to 1.250 inches (21.08-31.75 mm), accommodating various cable sizes.

• Terminals: Features box terminals with hex socket threaded slugs, permitting high clamping pressure on conductors without damaging strands.

• Environmental Ratings: Suitable for indoor dry environments unless additional protection is provided. Operates effectively in temperatures ranging from -40°C to 75°C without impact.

• Certifications: Listed to UL 498 and certified to CSA C22.2 No.42 standards, ensuring compliance with safety and performance requirements.

These features make the CS8264C connector suitable for heavy-duty industrial applications requiring secure and durable electrical connections.
