SF-Mobile WeldStar Laser Welding Machine | $500 Shipping via LA Warehouse

Introducing the Mobile WeldStar Breeze & Mobile WeldStar Aqua



Mobile WeldStar Breeze (air cooling): With 800W and 1200W power options, it’s perfect for versatile tasks. The compact, air-cooled design ensures efficient performance up to 3mm thickness.

Mobile WeldStar Aqua ( water cooling ): Equipped with advanced water-cooling technology and high-power options (up to 3000W), this system excels in intensive jobs and penetrates up to 14mm thick.

Technical Specifications

Model	Laser Power (W)	Weight (Kg)	Size (L×W×H mm)	Power Supply	Power Consumption (Kw)	Shield Gas
Mobile WeldStar Breeze	800W	103	1084×553×1186	220V Single Phrase	2.5	Nitrogen/Argon, Purity≥99.5%,Gas Pressure: 3-5 Bar
	1200W	107	1084×553×1186	220V Single   Phrase	3.8	Nitrogen/Argon, Purity≥99.5%,Gas Pressure: 3-5 Bar
Mobile WeldStar Aqua	1500W	192	1370×748×1186	220V Single Phrase	6.8	Nitrogen/Argon, Purity≥99.5%,Gas Pressure: 3-5 Bar
	2000W	201	1370×748×1186	220V Single Phrase	8.6	Nitrogen/Argon, Purity≥99.5%,Gas Pressure: 3-5 Bar
	3000W	211	1370×748×1186	380V Three Phrase	12.8	Nitrogen/Argon, Purity≥99.5%,Gas Pressure: 3-5 Bar

• DOWNLOAD for Mobile WeldStar Technical pdf
• DOWNLOAD for Mobile WeldStar User Manual pdf

Wire Feeder

Feature	Specification
Welding Wire Reel
Outer Diameter (OD)	≤300mm
Inner Diameter (ID)	≤53mm
Weight	≤30kg
Wire Diameter	0.8/1.0/1.2/1.6mm
Feeding Model	Manual/Auto
Feeding Speed	25-600cm/min
Wire Material	MS/SUS/ALUMINUM
Dual Wire Feeding	Optional

Welding Capacity

Material	Model	Single side welding depth	Double side welding depth
Stainless Steel (SUS)	Mobile WeldStar Breeze	Up to 3mm	Up to 6mm
Carbon Steel (MS)	Mobile WeldStar Breeze	Up to 3mm	Up to 6mm
Aluminum	Mobile WeldStar Breeze	Up to 3mm	Up to 6mm
Stainless Steel (SUS)	Mobile WeldStar Aqua	Up to 7mm	Up to 14mm
Carbon Steel (MS)	Mobile WeldStar Aqua	Up to 7mm	Up to 14mm
Aluminum	Mobile WeldStar Aqua	Up to 7mm	Up to 14mm



Comprehensive Design

As you can see, we euip this machine with a trolley to allow easily moving. In addition, we provide welding table and even an Welding Booth.

Laser Welding Vs Traditional Welding

Feature	Traditional Welding	Mobile WeldStar Laser Welding
Welding Speed	Normal	4× Faster
Welding Quality	Depends on operator’s experience	Consistently high-quality results
Learning Difficulty	Difficult	Easy and quick to learn
Pre-Weld Preparation	Critical and time-consuming	Minimal and fast
Material Flexibility	Limited by consumable changes	Broad, with no setup required
Heat Affected Zone	Large	Small
Warping and Deformation	Prone to deformation	Less prone to deformation
Swing Welding	Not available	Available – weld seam width up to 8mm

Shipping Information



Packing List
