Smart Cutting Head-Raytools-BS03K-CAT｜Built-in Height Adjusting Mechnism

Boost your cutting efficiency with the new Raytools BS-03K CAT cutting head. Achieve top speeds of up to 75m/min on both 1mm carbon steel and stainless steel, significantly faster than previous Raytools models and Precitec counterparts, which max out at 60m/min.

Caution:

• It supports ONLY EtherCAT bus communication.
• The BS03K-CAT laser cutting head is only compatible with the Raytools XC3000S Bus version.
• This cutting head cannot be used with other control software, such as FSCUT.



Technical  Parameter :

Technical Parameter	Value
Auto Focusing Range	-22mm to +22mm (F150mm)
Auto Focusing Speed	< 200mm/s
Auto Focusing Acceleration	< 10m/s²
Auto Focusing Precision	0.01mm
Aperture	0.14
Nozzle Specification	Single Layer, Double Layer, Non-standard
Nozzle Diameter	1.0mm, 1.2mm, 1.5mm, 2.0mm, 2.5mm, 3.0mm, 3.5mm, 4.0mm, 4.5mm, 5.0mm
Auxiliary Gas Pressure	< 30bar
Weight	7.4 kg

What’s in the box:

Download:

PRODUCT INTRODUCTION

Download our USER MANUAL hassle-free , accessible anytime, anywhere

Functions :

• Dual Optical Protection: Enjoy extended lifespan and enhanced sealing with three sets of protective lenses in the BS03K-CAT cutting head.

• Optimized Mechanical/Water Circuit Design: Simplified maintenance and anti-corrosion features ensure longevity and efficiency in operation.

• Optimized Optical and Airflow Design: Experience improved cutting speeds and performance by 10%-40% compared to conventional cutting heads.

• Built-in Capacitance Amplifier: Optional amplifier models allow for precise and stable height adjustments, enhancing cutting accuracy.

• Sensor/Protective Lens Temperature Monitoring: Real-time monitoring ensures precise gas control and reduces the probability of lens contamination, optimizing cutting quality.

• Collimation and Focusing: Faster focusing speed and wider focusing range support efficient cutting processes, including small nozzle full power carbon steel cutting.

• Equipment Interconnectivity, Intelligent Management: Utilize Cloud MES solution for efficient production management, real-time equipment status display, and alarm notifications, enhancing overall production efficiency and competitiveness.

Comparison of Carbon Steel Cutting Results :

Comparison for 6mm :

	BS03K-CAT	Competitor X
Material	Carbon Steel	Carbon Steel
Thickness	6mm	6mm



Comparison for 20mm (Small Nozzle):

	BS03K-CAT	Competitor X
Material	Carbon Steel	Carbon Steel
Thickness	20mm	20mm



Comparison for 20mm (Reduced Power) and 25mm CS (Small Nozzle) :

	BS03K-CAT	Competitor X
Material	Carbon Steel	Carbon Steel
Thickness	20mm 25mm	20mm 25mm



Comparison of Carbon Steel Cutting Speeds :

Comparison of Stainless Steel Air Cutting Result :

BS03CAT Air Cutting Performance	Competitor X Air Cutting Performance	BM110 Air Cutting Performance
1mm	1mm	1mm
2mm	2mm	2mm
5mm	5mm	5mm

Comparison of Stainless Steel Air Cutting Speeds :

XC3000S+BS03K-CAT Process Reference Parameters :

Material	Thickness (mm)	Height (mm)	Speed (m/min)	Assist Gas	Gas Pressure (bar)	Focus	Nozzle
CS	6	0.6	2.7	O2	0.75	6	1.2 Double Layer (20 Small Nozzle)
CS	1	0.3	0.5	O2	1.0	13	1.3 Single Layer (20 Reduced Power)
CS	13	1.3	0.6	O2	0.7	5	4.5 Double Layer (25)
SS	1	0.5	60	N2	10	0	2.0 Single Layer
SS	2	0.4	32	–	15	0	2.0 Single Layer
SS	5	0.4	4.5	–	17	-2.5	3.5 Single Layer
SS	1	0.5	75	Air	17	-0.5	1.7 Single Layer
SS	2	0.5	35	–	17	-0.5	2.0 Single Layer
SS	5	0.5	6.5	–	17	-3.0	3.5 Single Layer



Download our PDF guide hassle-free , accessible anytime, anywhere
