QM Drain Lagos VEIL Tile-in Linear Shower Drain

    $28.99

    Stylish minimalism. The Veil short linear drain opens up a whole new world of design freedom. It’s a tileable grate in five attractive finishes: stainless steel satin, polished, satin gold, black matte, and bronze. It couldn’t be easier to tailor to individual taste and requirements. resistant.FeaturesVariable positioning: Versatile, can be…

    SKU: XIL85007442 Category:
      Stylish minimalism. The Veil short linear drain opens up a whole new world of design freedom. It’s a tileable grate in five attractive finishes: stainless steel satin, polished, satin gold, black matte, and bronze. It couldn’t be easier to tailor to individual taste and requirements. resistant.

      Features

      • Variable positioning: Versatile, can be installed anywhere in the shower except shower entrance and can be combined with all standard tile formats.
      • Base: Pre-sloped low profile channel, ideal for new and renovation projects and generally for all bathrooms where space is tight.
      • Outlet: 2” center located outlet.
      • Material: Stainless steel marine grade 316 on all the edges in an ABS plastic body.
      • Easy cleaning: Completely removable grate and a hair strainer that fits inside the drain to collect hair and other debris, preventing clogged pipes.
      • Easy installation: Plain Edge is intended for use with standard waterproofing methods. Waterproofing is installed before the drain base is connected. Threaded adaptor with rubber O-ring aids adjusting the height of linear drain and securing the linear drain to the flange, equipped with adjustable feet on both sides, to help keep the drain channel in the correct position and level during installation.
      • The drain flange is not included in the kit, if needed add QM-83.FLG.2.CI , QM-83.FLG.2.PVC , QM-83.SQFLG.2.CI.
      • Application: Indoor and Outdoor showers.

      Resources

      Specification
      Center Drain Installation Instructions – Standard Waterproofing
      Watch installation video
      Warranty Info

      Reviews

      There are no reviews yet.

      Be the first to review “QM Drain Lagos VEIL Tile-in Linear Shower Drain”
