Creality CR-Scan Raptor X 3D Scanner

CR-Scan Raptor X 3D Scanner

A metrology-grade 3D scanner with a maximum accuracy of 0.02mm, and wireless scanning. With three light sources (blue light, white light, and infrared) you can simultaneously achieve large format high speed scanning of cross laser lines (34 lines), fine scanning of parallel laser lines (7 lines) and infrared scanning. Suitable for medium to large parts in a variety of fields like automotive, reverse engineering, product design, energy engineering and heavy industry.

Features

Specifications

Creality Raptor X

Scanning Mode	7 Blue Parallel Laser Lines	34 Blue Laser Lines	NR (IR binocular structured light)
Accuracy	up to 0.02mm	up to 0.02mm	up to 0.05mm
Volume Accuracy	0.02mm+0.06mm/m	0.02mm+0.06mm/m	0.05mm+0.1mm/m
Scanning Rate	420,000 measurements/s	1,020,000 measurements/s	3,580,000 measurements/s
3D Resolution	0.02-2mm	0.02-2mm	0.1-2mm
Scanning Speed	Up to 60fps	Up to 60fps	Up to 20fps
Minimum Scanning Volume	5mm x 5mm x 5mm	5mm x 5mm x 5mm	150mm x 150mm x 150mm
Single Capture Range	270mm x 170mm @300 mm	270mm x 170mm @300mm 397mm x 290mm @500mm 341mm x 232mm @400mm 452mm x 348mm @600mm	630mm x 550mm @1000mm
Working Distance	150mm-400mm	200-600mm	170mm-1200mm
Color Mapping	Support	Support	Support
Alignment Mode	Marker	Marker	Marker/Geometry/Texture
3D Imaging Camera Resolution	1920 x 1200	1920 x 1200	1920 x 1200
RGB Color Supplemental Light	12 white LEDs	12 white LEDs	12 white LEDs
Outdoor Scanning	Below 50,000 lux	Below 100,000 lux	Below 30,000
Marker Recognition Enhancement	12 Blue LEDs	12 Blue LEDs	12 Blue LEDs
Laser Safety	Class I (eye safe)	Class II (eye safe)	Class I (eye safe)
Button	Mechanical	Mechanical	Mechanical
IMU	Support	Support	Support
Output Format	OBJ/STL/PLY	OBJ/STL/PLY	OBJ/STL/PLY
Input Power	12V 2A	12V 2A	12V 2A

*Free One Year Manufacturer Warranty
