STK LMS Line Series Line Array

    $119.99

    LMS-62P line array2 Way Passive Full Range Bi System. Used double PCS of 12mm birch plywood materials to making a super-durable enclosure. High-quality components with an environmentally friendly, lightweight, and field-repairable waterborne polymer finished with scratchproof finished suspension materials. Have a dual 2 pairs of powerful 6.5‚” low-frequency drivers. Both have wide…

    SKU: LIH63695176 Category:
      LMS-62P line array

      2 Way Passive Full Range Bi System. Used double PCS of 12mm birch plywood materials to making a super-durable enclosure. High-quality components with an environmentally friendly, lightweight, and field-repairable waterborne polymer finished with scratchproof finished suspension materials. Have a dual 2 pairs of powerful 6.5‚” low-frequency drivers. Both have wide 110 horizontal coverage at the crossover with extends the mid-range. High frequencies handled by SK-70D HF drivers with a converging lens of SFG10 for ultimate sound reproduction.
      LMS-6015P subwoofer
      Passive single 15″ Sub Woofer System, the systems can be readily integrated into arrays of full range LMS-62P line array elements. Ported + vented rectangular enclosure. SK 15600 15″ high power transducers provide to solid sounding output.
      “Used 12mm birch plywood materials by double PCS to making a super-durable enclosure. High-quality components with an environmentally friendly, lightweight field-repairable waterborne polymer finished with scratchproof finished suspension materials.
      Combined LMS-62 and LMS-6015 arrays making suspension with optinal array frame(B6015 LMH), can also be used to ground-sacked for extended range front of house system with optional U-FRAME(B62 LMU) with 2 of SPM-35150 speaker poles.





      Model LMS-62P
      Configuration 2-way Full-Range, Bi-amp
      High-frequency Transducer SK-70D HF Driver on SFG 10(Converging Lens)
      Low-frequency Transducer SK65200FP, 6.5″(162mm) woofer x 4.
      Frequency Response (3dB) 80 Hz – 20kHz
      Frequency Range (-10dB) 65Hz – 23kHz
      Nominal Impedance LF : 16 Selectable / HF : 16 Fixed
      Continuous Power Capacity HF : 70W/280W PEAK
      LF : 360W/1440WPEAK
      Sensitivity (SPL, 1 W at 1 m) HF : 105dB
      LF : 100dB
      Recommended Power HF : 140W
      LF : 720W
      Maximum Output, Continuous/Peak
      (dB SPL at 1 m)      		 HF: 123.47dB /129.47dB
      LF: 125.58dB /131.58dB
      Nominal Coverage H : 110
      V: Dependent on the number of elements used
      Enclosure Type Ported, trapezoidal
      Enclosure Material 2 x 12 mm birch plywood
      Finish Available in black or White(Option), paintable
      Grille Perforated, powder-coated 16AWG steel,
      Connectors For Amplifiers 2x Neutrik Speakon in parallel
      Pins: 1+/1- LF
      Pins: 2+/2- HF
      Controls for Select LF Impedance 4 ohm/off/16 ohm by up-down switch
      Controls for Select HF Sound Level Normal/off/-3dB by up-down switch
      Attachment Points Integral, “I” plate adjustable rigging system, vertical
      splay adjustable in 1 increment from 0-10



      Model LMS-6015P
      Configuration Sub Woofer: Line Array
      Transducer one SK15600 15″
      Frequency Response (± 3dB) 40Hz – 200Hz
      Frequency Range (-10dB) 35Hz – 500Hz
      Nominal Impedance 8
      Continuous Power Capacity 600W/2400W PEAK
      Sensitivity (SPL, 1 W at 1 m) 99 dB
      Recommended Power 1200W
      Maximum Output,Continuous/Peak(dB 126.80dB /132.80dB
      SPL at 1 m)
      Enclosure Type Ported + Vented subwoofer rectangular type
      Enclosure Material 2 x 12 mm birch plywood
      Finish Available in black or White(Option), paintable
      Grille Perforated, powder-coated 16AWG steel,
      Connectors For Amplifiers 2x Neutrik Speakon in parallel
      Pins: 1+/1- SUB
      Pins: 2+/2- NC
      Attachment Points Integral, non-adjustable.straight array on
